If your crew opens manholes every day, you already know the drill: wedge a hook bar into the pick hole, brace your back, and pull. It gets the cover off. It also puts your workers one bad lift away from a serious injury.
U.S. Saws’ Aluminum Heavy Duty Collapsible Dollies were built to change that. These magnetic manhole lifter systems combine powerful magnetic attachment with a collapsible aluminum dolly frame, giving operators complete control over lifting and transporting heavy covers, without a pry bar in sight.
This post covers how the magnetic manhole lifting dollies work, who they’re built for, and why the investment pays off fast.
Why Manual Manhole Lifting Is a High-Risk Task
Manhole covers are not light. Cast iron lids commonly weigh anywhere from 90 to 250 pounds or more. When a worker bends down, hooks a pick into the cover, and lifts from a ground-level position, the lower back absorbs the full load. Do that repeatedly across a shift, and the risk compounds quickly.
The data backs this up. According to the Bureau of Labor Statistics, over 80,000 workplace injuries annually are directly linked to carrying and lifting at work. NIOSH reports that back injuries account for nearly one-third of all workplace injuries involving days away from work. A loss alert published by CIRSA, a municipal risk pool serving Colorado government entities, found that manhole cover lifting claims totaled close to half a million dollars over a five-year period, with a single rotator cuff injury alone exceeding $130,000 in costs.
Beyond back injuries, pry bar work introduces a second hazard: loss of control. A cover that’s stuck will not budge, then suddenly gives way. Whoever is holding that bar pays the price.
“The thing about a pry bar is you’re never in control — the cover is. It’s stuck, it’s stuck, it’s stuck — then it’s not, and whoever’s holding that bar pays the price. The dolly puts the operator back in control from start to finish.” — Bill Glynn, President of Water & Sewer Division, U.S. Saws
How the Magnetic Manhole Lifter Dolly System Works
The system has two components that work together: a heavy-duty magnet that bonds directly to the surface of the manhole cover, and a collapsible aluminum or steel dolly frame that gives the operator mechanical control over lifting and transport.
There are no hooks, chains, or prying involved. The magnet attaches flat to the cover surface. Once the operator engages the lift, the cover comes straight up and is ready to roll. The collapsible frame keeps the total system weight manageable at just 23 lbs, making it easy for one person to deploy and operate.
A key engineering feature is the dual lift position system. By moving the dolly closer to the magnet, the operator doubles the pull-out force. This second position is specifically designed to break covers loose when they’re stuck or seated tight from corrosion, without the operator exerting additional physical force.
The magnet must be in full contact with the cover before it engages, which means accidental activation is not possible. No loose cables, no mechanical clamps, no awkward positions that put workers at risk during the lift.
A key engineering feature is the dual lift position system. By moving the dolly closer to the magnet, the operator doubles the pull-out force. This second position is specifically designed to break covers loose when they’re stuck or seated tight from corrosion, without the operator exerting additional physical force.
The magnet must be in full contact with the cover before it engages, which means accidental activation is not possible. No loose cables, no mechanical clamps, no awkward positions that put workers at risk during the lift.
Choosing the Right Manhole Cover Lift for Your Crew
U.S. Saws offers two primary aluminum dolly configurations to match the weight range your crew works with.
300 lb. Aluminum Heavy Duty Collapsible Dolly handles the vast majority of residential and light commercial manhole covers. It’s the right choice for municipal water and sewer crews working standard infrastructure.
600 lb. Aluminum Heavy Duty Collapsible Dolly is the right call for highway-grade covers, large industrial manholes, or any situation where the crew is not certain of the cover weight going in. When in doubt, go with the higher-capacity system.
Steel dolly variants are also available for crews that prefer a steel chassis. Both the 300 lb. and 600 lb. configurations are offered in curved heavy duty collapsible steel dollies, and a
900 lb. capacity option is available for the most demanding applications.
Manhole Lifter Portability: Built for Real Job Sites
Portability matters when you’re moving between job sites all day. The dolly frame collapses to 36” × 12.5” × 11.6”, small enough to ship via UPS and easy to store in a truck bed or gang box. The dolly and magnet separate into two independent components, so getting the equipment to the cover is not a second obstacle even when working short-handed.
Who Needs a Magnetic Manhole Lifter Dolly?
These systems were designed for any crew that regularly accesses below-grade infrastructure:
- Municipal water and sewer departments
- Utility contractors
- Highway and DOT maintenance teams
- Private industrial facility operators managing underground utilities
If your crew is opening manholes more than a few times a week, the manual lifting risk is real and cumulative. The dolly removes that risk entirely.
The ROI on Safer Manhole Cover Lifting
A single back injury workers’ comp claim can easily run into tens of thousands of dollars in direct costs, lost time, and crew disruption. Either dolly system pays for itself quickly when measured against that exposure.
There’s also a productivity argument. Crews using the dolly system move faster because the lift is controlled and predictable. No struggling with stuck covers, no recovery time after a near-miss, no worn-out pry bars to replace.
“I don’t sell equipment — I sell fewer injuries, faster job completion, and crews that go home the same way they show up. The dolly just happens to be how we get there.” — Bill Glynn, President of Water & Sewer Division, U.S. Saws
Part of a Complete Magnetic Manhole Lifter System
The dollies work alongside U.S. Saws’ full line of magnetic manhole lifter products. If your crew needs a lift-only solution without transport capability, the Break ’N Take and Robotron systems handle covers in tight spaces or high-frequency applications. For a full breakdown of the magnetic lifter product line, see our guide to
why smart crews are switching to magnetic manhole lifters.
See the Full Magnetic Lifting Dolly Line
U.S. Saws offers aluminum and steel dolly configurations from 300 to 900 lb. capacity, with magnet and frame options that can be purchased together or separately. Browse the full selection and find the right system for your crew at ussaws.com/magnetic-lifting-dollies.
Sources:
Bureau of Labor Statistics. Injuries, Illnesses, and Fatalities. bls.gov/iif
CIRSA Loss Control Department. (2009). Loss Alert: Frequent Injuries While Lifting Manhole Covers. cirsa.org
